Superior design and advanced features combine to give Cat® Telehandlers the best all-around visibility and take the lead in lift and reach capability. Top performance, rugged construction for reliability and durability with low operating costs.
SPECS
| Engine Model |
Cat® C3.4B |
| Gross Power (Basic) |
75.0 kW |
| Note |
Meets U.S. EPA Tier 4 Final emission standards. |
WEIGHTS
| Operating Weight |
10400.0 kg |
OPERATING SPECIFICATIONS
| Rated Load Capacity |
2948.0 kg |
| Maximum Lift Height |
12.8 m |
| Maximum Forward Reach |
9.1 m |
| Top Travel Speed |
32.0 km/h |
| Capacity at Max Height (o/r Up) |
2722.0 kg |
| Capacity at Max Height (o/r Down) |
2949.0 kg |
| Capacity at Max Reach (o/r Up) |
272.0 kg |
| Capacity at Max Reach (o/r Down) |
771.0 kg |
| Frame Leveling |
10° |
| Turning Radius over Tires |
3.7 m |
| Drawbar Pull (Loaded) |
88.0 kN |
TIRES
| Standard |
370/75-28 Air Duraforce |
| Optional |
370/75-28 Foam Duraforce |
| Optional |
13.00 × 24-16 PR Air |
| Optional |
13.00 × 24-12 PR Foam Filled |
| Optional |
13.00 × 24 Solid |
HYDRAULIC SYSTEM
| Gear Pump |
Single-section |
| System Operating Pressure |
260.0 bar |
| Auxiliary Hydraulic Pressure |
240.0 bar |
| Auxiliary Hydraulic Flow |
68.0 L/min |
| Note |
Auxiliary Hydraulic Circuit used for all attachments equipped with cylinders or other hydraulic components. |
SERVICE REFILL CAPACITIES
| Fuel Tank |
145.0 L |
| Diesel Exhaust Fluid (DEF) Tank |
21.5 L |
| Hydraulic System |
158.0 L |
BOOM PERFORMANCE
| Boom Up |
15.5 Seconds |
| Boom Down |
10.7 Seconds |
| Tele In |
11.8 Seconds |
| Tele Out |
17.0 Seconds |
BRAKES
| Service Brakes |
Inboard wet disc brakes on front and rear axles |
| Parking Brakes |
Wet disc, spring applied hydraulic release on front axle |
AXLES
| Type |
Trunnion mounted planetary 55 degree steer axles |
| Type |
High bias limited slip differential on front axle |
TRANSMISSION SPEEDS
| Forward |
4 speed |
| Reverse |
3 speed |
WORK TOOLS
| Hydraulic IT Coupler |
Includes Auxiliary Electrics |
| Pallet Forks – Option 1 |
[2] 1220 mm, 60 mm × 125 mm ([2] 48 in, 2.36 in × 5 in) |
| Pallet Forks – Option 2 |
[2] 1220 mm, 60 mm × 100 mm ([2] 48 in, 2.36 in × 4 in) |
| Pallet Forks – Option 3 |
[2] 1525 mm, 60 mm × 150 mm ([2] 60 in, 2.36 in × 6 in) |
| Lumber Forks – Option 1 |
[2] 1525 mm, 45 mm × 180 mm ([2] 60 in, 1.75 in × 7 in) |
| Lumber Forks – Option 2 |
[2] 1829 mm, 50 mm × 150 mm ([2] 72 in, 2 in × 6 in) |
| Cubing Forks |
[2] 1220 mm, 50 mm × 50 mm ([2] 48 in, 2 in × 2 in) |
| Carriages: Standard Tilt |
1270.0 mm |
| Carriages: Wide Tilt |
1829.0 mm |
| Carriages: Side Shift |
1220.0 mm |
| Carriages: Standard Rotate |
1270.0 mm |
| Carriages: Wide Rotate |
1829.0 mm |
| Carriages: Swing |
100°, 1829 mm, 2948 kg Capacity, 2268 kg Swung (100°, 72 in, 6,500 lb Capacity, 5,000 lb Swung) |
| Carriages: Dual Fork Positioning |
1270.0 mm |
